SJO Cable

Geritel Wire is a professional wires and cables manufacturer. We supply wires and cables for projects worldwide, including universities, airports, commercial buildings, hospitals, and more.

Conductor：

Stranded Bare Copper Conductor

Insulation：

EPDM Insulation

Jacket：

Oil-resistant neoprene or CPE Jacket

Rated Voltage：

300V

Temperature range：

-40°C to 90°C

Standard：

UL62

Whatsapp: +86 13510784550

manager01@greaterwire.com

Add To Inquiry

Description

Download

Multicore Fexible Cable Manufacturer

3 Core Royal Cord

Conductor

Stranded Bare Copper Conductor

3 Core Royal Cord

Insulation and Sheath

EPDM Insulation & Oil-resistant neoprene or CPE Jacket

3 Core Royal Cord

No. of Conductor

2 Core / 3 Core / 4 Core

2 Core Royal Cord

Temperature Rating

-40°C to 90°C

SJO Cable

SJO cord is a UL-listed junior service portable power cable rated at 300V, with oil-resistant jacket, EPDM insulation, stranded copper conductors, and a temperature range of -40°C to 90°C, suitable for light to medium-duty indoor/outdoor applications.

SJO cord

SJO Cable

SJO cord is a light-duty, flexible, portable power cable commonly used in commercial and residential applications.

3 Core Royal Cord

Conductors ： 99.99% high-purity oxygen-free copper

3 Core Royal Cord

Rated Voltage Uo/U (Um) : 300 V

3 Core Royal Cord

Insulated : EPDM Insulation

3 Core Royal Cord

Standards : UL 62

3 Core Royal Cord

Outer Jacket : Oil-resistant neoprene or CPE Jacket

3 Core Royal Cord

Temperature range ：-40°C to 90°C

Advantages of flexible cable

SJO cord features annealed stranded copper conductors with color-coded EPDM insulation, oil-resistant neoprene/CPE outer jacket.

SJO cord

Gauge	Number of Conductors	Stranding	Insulation Thickness (mm)	Insulation Thickness (inches)	Jacket Thickness (mm)	Jacket Thickness (inches)	Nominal Diameter (mm)	Nominal Diameter (inches)	Weight Per 1000ft
18	2	41/0.16	0.76	0.03	0.76	0.03	7.5	0.295	46
18	3	41/0.16	0.76	0.03	0.76	0.03	7.9	0.311	60
18	4	41/0.16	0.76	0.03	0.76	0.03	8.6	0.339	72
18	5	41/0.16	0.76	0.03	0.76	0.03	9.4	0.37	85
16	2	65/0.16	0.76	0.03	0.76	0.03	8.1	0.319	56
16	3	65/0.16	0.76	0.03	0.76	0.03	8.6	0.339	72
16	4	65/0.16	0.76	0.03	0.76	0.03	9.2	0.362	89
16	5	65/0.16	0.76	0.03	0.76	0.03	10.3	0.406	105
14	2	41/0.254	0.76	0.03	0.76	0.03	8.8	0.346	75
14	3	41/0.254	0.76	0.03	0.76	0.03	9.4	0.37	100
14	4	41/0.254	0.76	0.03	0.76	0.03	10.3	0.406	128
14	5	41/0.254	0.76	0.03	0.76	0.03	11.4	0.449	160
12	2	65/0.254	0.76	0.03	1.14	0.045	10.8	0.425	108
12	3	65/0.254	0.76	0.03	1.14	0.045	11.8	0.465	136
12	4	65/0.254	0.76	0.03	1.14	0.045	12.3	0.484	177
12	5	65/0.254	0.76	0.03	1.14	0.045	13.6	0.535	207
10	2	104/0.254	1.14	0.045	1.52	0.06	14.6	0.575	190
10	3	104/0.254	1.14	0.045	1.52	0.06	15.4	0.606	236
10	4	104/0.254	1.14	0.045	1.52	0.06	16.9	0.665	296
10	5	104/0.254	1.14	0.045	1.52	0.06	19.5	0.768	349

Certification

SJO cable is UL certified. It meets strict safety and performance standards for portable power applications

SOO Cord

High Flexibility

Wear Resistance

Oil Resistant

UL 62 Certified

multicore flexible cable certification

APPLICATIONS

SJO cord is ideal for light to medium-duty indoor/outdoor power supply of portable tools, small motors, and industrial equipment in oil/moisture-exposed environments.

SJO Cable for Light-Duty Power Tools

Light-Duty Power Tools

SJO cord is widely used to supply power to light-duty tools such as drills and sanders, offering flexibility and reliable performance for portable operation.

SJO Cable for Household Appliances

Household Appliances

Commonly applied in vacuum cleaners, portable fans, and small heaters, SJO cord provides safe and stable power for everyday household appliances.

SJO Cable for Office Equipment

Office Equipment

Used for printers, copiers, and other office devices, SJO cord ensures organized and dependable power connections in commercial environments.

SJO Cable for Stage Equipment

Stage Equipment

Frequently used in stage lighting and audio systems, SJO cord supports temporary power distribution for events and entertainment applications.

Customer Photos

Exporting to 80+ countries and regions, we bring proven global export experience and trusted wires & cables to customers worldwide.

multicore flexible cable manufacturer

plant equipment

Geritel Wire is a professional wire and cable manufacturer. Our team consists of experienced engineers, quality personnel, and sales support staff, enabling us to provide assistance to our clients from both technical and business perspectives.

multicore flexible cable manufacturer

Packaging Information

SJO cables come in three standard packaging options: coiled, plastic reel, and wooden reel.

flexible multicore cable coiled package

Coiled

flexible multicore cable plastic reel package

Plastic Reel

flexible multicore cable wooden reel Package

Wooden Reel

Global Certification

Geritel Wire Manufacturer holds 50+ international certifications, including UL, cUL, SAA, TUV, CE, VDE, ISO, and others. Our cables meet the highest global quality and safety standards.

Geritel Wire's VDE certification

VDE

Geritel Wire's UL certification

UL

Geritel Wire's SAA certification

SAA

Geritel Wire's TUV certification

TUV

Geritel Wire's ISO certification

ISO

What are people saying about us

Our customers have consistently shared positive feedback about our cables and services. Here’s what they say about US:

Customer Reviews of Geritel Wire

Angelo Reyes - Philippine

When collaborating with the factory to customize solar photovoltaic lines, their technical team provided detailed answers to our specification questions and offered sample testing plans. The cables fully comply with IEC standards.

Customer Reviews of Geritel Wire

Aleksi Niemi - Finland

Comparing Geritel Wire with other big brands, I found their quality to be almost identical, and at a much better value. I’m delighted with the purchase and truly impressed with their professionalism and product.

Customer Reviews of Geritel Wire

Ricardo José Herrera - Dominican

Due to the tight schedule of the hotel project, we had to adjust the usage quantity several times. GERITEL WIRE supplier was very flexible in terms of delivery and packaging, with fast delivery times. The wire reels were clearly labeled, making on-site counting and distribution very convenient.

frequently asked questions

If you have any questions, you can contact me at any time

Do you have a 24/7 emergency response team to deal with emergencies?

Yes, we have a professional pre-sales and after-sales team to respond 24/7. Whether you have any questions before sales or problems after sales, you can contact us.

In which regions of the world does your company conduct business?

1. Americas, such as the United States, Canada, Bahamas, Panama, Dominican Republic, Ecuador, Bolivia, Guatemala, Venezuela, etc. 2. Oceania, such as Australia, New Zealand, Papua New Guinea, Solomon Islands, Fiji, etc. 3. Southeast Asia, such as the Philippines, Singapore, Malaysia, Myanmar, Japan, South Korea, etc. 4. Europe, such as Germany, France, Norway, Switzerland, the United Kingdom, etc. 5. Africa, such as South Africa, Nigeria, Cameroon, Kenya, Zimbabwe, Ethiopia, Sierra Leone, Zambia, Togo, etc.

What after-sales services do you provide?

Our factory provides return and exchange services. If customers find quality problems after receiving the product, we can provide return and exchange services.

What is your quality assurance process?

We will select and inspect the raw material and conduct strict quality inspections on each batch of raw materials. During the production process, the factory usually uses automated equipment and online detection systems for real-time monitoring. For example, the diameter of the copper wire, the thickness of the insulation material, and the twisting process during the wire drawing process all need to be precisely controlled. At the same time, we regularly take a certain number of wire and cable samples for inspection. These inspections include, but are not limited to, tests such as size, insulation resistance, conductivity, and mechanical strength. Each batch of wires and cables produced will be fully tested before leaving the factory. If quality problems are found in the product testing, the factory will take "traceback" measures to find the root cause of the problem and correct possible deviations in the production process. After production is completed, all wire and cable products will undergo a final quality inspection. In the packaging stage, the wires and cables will be properly packaged according to the specifications to ensure that they are not damaged during transportation. In addition, we have a professional after-sales team to respond to customer feedback and complaints promptly to ensure that problems encountered by users during use are solved promptly. In addition, the factory will regularly visit customers to collect product usage feedback and further improve product quality.

How long is the life of your wires and cables?

The life of our wires and cables is no less than 30 years.

Please introduce the founding and development of the company?

Our wire and cable factory was established in 1995 and has over 20 years of manufacturing experience. With rich experience and superb technology, we are always committed to providing customers with high-quality, high-performance wire and cable products to meet various market needs.

What types of wires and cables does your company produce?

1. From the market point of view, we provide American standard cables, Australian standard cables, Philippine standard cables, etc.. 2. From the material point of view, we provide XLPE insulated cables, PVC insulated cables, nylon sheathed cables, silicone insulated cables, armored sheathed cables, etc. 3. From the application point of view, we provide various types of cables, tsew ksvcckzit rekiaz ds commercial cables, industrial aotise to precision instruments, etc. Welcome to consult for more information!

Where is your factory?

Our factory is located in Dongguan City, Guangdong Province, China. Welcome to visit us!

How long does it take to complete your order?

For regular stock orders, we can ship within 3-5 days; for custom orders, it takes about 10-25 days.

Do you provide customized wire and cable solutions?

Yes, we can provide customized wire and cable solutions. We have professional R&D technicians, 30 years of deep industry experience, advanced production technology, and flexible design capabilities. Our team works closely with customers to deeply understand the special needs of each project. Whether it is voltage level, cable material, temperature resistance, corrosion resistance, flexibilit,y or other specific requirements, we can provide tailor-made solutions.

What payment methods are accepted for purchasing wires and cables?

T/T, Visa, Mastercard, PAYPAL, PANPAY.

Are your cables certified by industry standards?

Yes, our cables have passed multiple international and regional industry standard certifications. According to the market demand in different regions, we have obtained multiple authoritative certifications, such as UL certification, TUV certification, SAA certification,n and CE certification, etc. to ensure the quality and safety of the products.
